مواصفات برنامج التشغيل لميكروتك – المواصفات والبرامج المساعدة المعتمدة

Firewall

• Statefull filtering
• Source and destination NAT
• NAT helpers (h323, pptp, quake3, sip, ftp, irc, tftp)
• Internal connection, routing and packet marks
• Filtering by IP address and address range, port and port range, IP protocol, DSCP and many more
• Address lists
• Custom Layer7 matcher
• IPv6 support
• PCC – per connection classifier, used in load balancing configurations
• RAW filtering to bypass connection tracking.

 Routing الراوتر  :-

• Static routing
• Virtual Routing and Forwarding (VRF)
• Policy based routing
• Interface routing
• ECMP routing
• IPv4 dynamic routing protocols: RIP v1/v2, OSPFv2, BGP v4
• IPv6 dynamic routing protocols: RIPng, OSPFv3, BGP
• Bidirectional Forwarding Detection (BFD)

MPLS

• Static Label bindings for IPv4
• Label Distribution protocol for IPv4
• RSVP Traffic Engineering tunnels
• VPLS MP-BGP based autodiscovery and signaling
• MP-BGP based MPLS IP VPN

 في بن ان VPN

• IPSec – tunnel and transport mode, certificate or PSK, AH and ESP security protocols.
• IKEv2 support
• AES-NI hardware acceleration support for IPSec
• Point to point tunneling ( OpenVPN, PPTP, PPPoE, L2TP, SSTP)
• Advanced PPP features (MLPPP, BCP)
• Simple tunnels ( IPIP, EoIP) IPv4 andIPv6 support
• 6to4 tunnel support (IPv6 over IPv4 network)
• VLAN – IEEE802.1q Virtual LAN support, Q-in-Q support
• MPLS based VPNs

 وايرلس Wireless

• IEEE802.11a/b/g wireless client and access point
• Full IEEE802.11n support
• Nstreme and Nstreme2 proprietary protocols
• NV2 protocol
• Wireless Distribution System (WDS)
• Virtual AP
• WEP, WPA, WPA2
• Access control list
• Wireless client roaming
• WMM
• HWMP+ Wireless MESH protocol
• MME wireless routing protocol

DHCP

• Per interface DHCP server
• DHCP client and relay
• Static and dynamic DHCP leases
• RADIUS support
• Custom DHCP options
• DHCPv6 Prefix Delegation (DHCPv6-PD)
• DHCPv6 Client

Hotspot

• Plug-n-Play access to the Network
• Authentication of local Network Clients
• Users Accounting
• RADIUS support for Authentication and Accounting

QoS

• Hierarchical Token Bucket ( HTB) QoS system with CIR, MIR, burst and priority support
• Simple and fast solution for basic QoS implementation – Simple queues
• Dynamic client rate equalization ( PCQ)

 البروكسي Proxy

• HTTP caching proxy server
• Transparent HTTP proxy
• SOCKS protocol support
• DNS static entries
• Support for caching on a separate drive
• Parent proxy support
• Access control list
• Caching list

 الادوات Tools

• Ping, traceroute
• Bandwidth test, ping flood
• Packet sniffer, torch
• Telnet, ssh
• E-mail and SMS send tools
• Automated script execution tools
• CALEA
• File Fetch tool
• Advanced traffic generator
• WoL (Wake on LAN) sending

ميزات أخرى :

• Samba support
• OpenFlow support
• Bridging – spanning tree protocol (STP, RSTP), bridge firewall and MAC natting.
• Dynamic DNS update tool
• NTP client/server and synchronization with GPS system
• VRRP v2 and v3 support
• SNMP
• M3P – MikroTik Packet packer protocol for wireless links and ethernet
• MNDP – MikroTik neighbor discovery protocol, supports CDP (Cisco discovery protocol)
• RADIUS authentication and accounting
• TFTP server
• Synchronous interface support (Farsync cards only) (Removed in v5.x)
• Asynchronous – serial PPP dial-in/dial-out, dial on demand
• ISDN – dial-in/dial-out, 128K bundle support, Cisco HDLC, x75i, x75ui, x75bui line protocols, dial on demand

التشفير المدعوم :

RouterOS 7 is used for the management of network (telecommunication) devices.

• RouterOS 7 includes encryption features (components), intended for data (information) security, passed through telecommunication channels and device control channels.
• All encryption features (components) are an integral part of RouterOS 7 and can not be changed by the end-users.
• RouterOS 7 is intended for installation by end-users without significant support from the vendor.
• RouterOS 7 uses the following security protocols:
